Radiator semi-automatic clinching machine radiator making machine

Radiator crimpling machine
May 12, 2022
Category Connection: Radiator Making Machine
Chat Now Contact Us
Tags:
#220V radiator production line #20mm Indenter Radiator Making Machine #200 models radiator crimping tool
Brief: See the solution in real use and note how it behaves under normal conditions. This video demonstrates the semi-automatic clinching machine for aluminum radiator plastic water tanks, showing how it efficiently crimps all four sides of the core simultaneously without manual pressing. Watch as we showcase its programmable settings for over 200 models and explain its suitability for single-model, high-quantity production in the auto industry.
Related Product Features:
  • Programmable for over 200 models, enabling flexible positioning press production.
  • Simultaneously crimps tabs on all four sides of the radiator core for high efficiency.
  • Operates with servo pneumatic drive and requires 0.8Mpa air pressure.
  • Features adjustable running speed and a production efficiency of 60-80 units.
  • Equipped with 8-12 cylinders and customizable molds for various tank shapes.
  • Compact machine dimensions of 1800*1600*1800mm with a weight of 1100kgs.
  • Suitable for single-model, high-quantity production in the automobile industry.
  • Simple operation with 3-direction adjustment and 4 workstations for streamlined workflow.
FAQs:
  • Is it convenient for workers to operate the semi-automatic crimping machine?
    Yes, the semi-automatic crimping machine requires only simple training for workers, making operation convenient and straightforward.
  • How many types of automatic crimping machines are available, and what are their features?
    There are three main types: single-side single crimping head (simple, low cost, low efficiency), single-side two crimping heads (higher speed, narrow side needs separate tool), and models with crimping heads on both sides (highest efficiency, handles all sides in one station, though narrow sides may require additional tools).
  • Which is better: automatic or semi-automatic crimping machine?
    The automatic crimping machine is ideal for single-model orders of 300 sets or more, while the semi-automatic version is better suited for production with many models but smaller quantities per model.
  • How many models can the automatic crimping machine system store?
    The PLC interface allows storage of up to 200 different models and positions, covering most car radiator models available.
