316L Stainless Steel Braided Aluminum Brazing Furnace with Nitrogen Purity Above 99.9995% and 2-3min Heating Time

Product Description:

The Aluminum Brazing Furnace is a cutting-edge industrial equipment designed for efficient and precise aluminum brazing processes. With its advanced features and high-performance capabilities, this furnace is an excellent choice for various manufacturing industries.

One of the key attributes of the Aluminum Brazing Furnace is its rapid heating up time, ranging from 0.5 to 1 hour. This quick heating process enables swift production cycles and ensures timely completion of brazing operations, enhancing overall productivity.

The face height of the mesh belt in this furnace is set at 900mm, providing ample space for accommodating aluminum components of various sizes and shapes. This generous face height allows for versatile brazing applications, making the furnace suitable for a wide range of production requirements.

Equipped with a state-of-the-art PLC Control System, the Aluminum Brazing Furnace offers precise and reliable control over the brazing process. The programmable logic controller ensures accurate temperature regulation and seamless operation, allowing operators to monitor and adjust settings with ease.

Operating within a brazing heating temperature range of 600 to 650℃, this furnace delivers consistent and uniform heat distribution to ensure optimal brazing results. The controlled temperature settings facilitate the bonding of aluminum components with precision and efficiency, producing high-quality brazed assemblies.

For enhanced process efficiency and product quality, the Aluminum Brazing Furnace features a nitrogen protection system with a purity level above 99.9995%. This nitrogen atmosphere provides a clean and controlled environment for brazing operations, preventing oxidation and ensuring the integrity of the aluminum components.

The Aluminum Brazing Furnace is specifically designed to accommodate components such as 250mm Maximum Height Aluminum Radiators, offering a specialized solution for brazing applications in the automotive and HVAC industries. With a nitrogen consumption rate of 35 to 45m³/h, this furnace delivers consistent and reliable performance for demanding production environments.

In conclusion, the Nitrogen Protection Aluminum Brazing Furnace with a face height of 900mm, PLC Control System, brazing heating temperature of 600-650℃, and nitrogen purity above 99.9995% is a top-of-the-line industrial furnace that combines precision, efficiency, and reliability to meet the diverse brazing needs of modern manufacturing processes.

Features:

• Product Name: Aluminum Brazing Furnace
• Heating Method of brazing section: Plug-in Heating Element
• Size: Customized
• Mesh belt transmission speed: 200—1500mm/min (Continuously Adjustable )
• Rated power of Drying zone: 103.45KW
• Maximum height of workpiece: 250mm

Technical Parameters:

Applications:

Sunhope Aluminum Brazing Furnace is a high-quality industrial equipment designed for various applications in the manufacturing industry. With its exceptional features and specifications, this product is ideal for a wide range of product application occasions and scenarios.

One key attribute of the Sunhope Aluminum Brazing Furnace is its maximum height of 250mm, making it suitable for brazing aluminum radiators with varying sizes and configurations. Whether you are working on small or large radiator components, this furnace can accommodate them all with ease.

Additionally, the furnace is equipped with a 316L stainless steel braided mesh belt, ensuring durability and reliability during the brazing process. This feature makes it perfect for continuous tunnel-type natural gas brazing ovens, where precision and consistency are crucial.

Another standout feature of this furnace is its nitrogen purity of above 99.9995%, which is essential for achieving high-quality brazing results. The furnace's nitrogen consumption of 35-45m³/h ensures efficient operation while maintaining the desired atmosphere inside the brazing chamber.

Furthermore, the Sunhope Aluminum Brazing Furnace operates on three-phase 50Hz power supply, offering versatility and compatibility with various industrial settings. Its temperature accuracy of ±3℃ guarantees precise control over the brazing process, resulting in uniform heating of radiator tubes and optimal brazing outcomes.

Whether you are in the automotive, HVAC, or manufacturing industry, the Sunhope Aluminum Brazing Furnace is the perfect solution for your brazing needs. Its advanced features, reliable performance, and sturdy construction make it a valuable asset for any production line requiring aluminum brazing capabilities.

Choose Sunhope Aluminum Brazing Furnace for efficient, precise, and high-quality brazing operations, and elevate your manufacturing processes to new heights of productivity and excellence.

Customization:

Product Customization Services for the Sunhope Aluminum Brazing Furnace:

Continuous tunnel type Natural gas brazing oven with Nitrogen protection for aluminum Brazing furnace

Brand Name: Sunhope

Place of Origin: Guangdong, China

Nitrogen Purity: Above 99.9995%

Cooling Method: Air Cooling

Heating Method: Radiant Tube Heating

Size: Customized

Mesh belt transmission speed: 200—1500mm/min (Continuously Adjustable)

Four Sections Aluminum Brazing Furnace 650-700 Degree Spray Drying Air Cooling Area
