Energy Saving Aluminum Brazing Furnace ±3C Temperature Accuracy Adjustable Belt Speed

  • Energy Saving Aluminum Brazing Furnace ±3C Temperature Accuracy Adjustable Belt Speed
  • Energy Saving Aluminum Brazing Furnace ±3C Temperature Accuracy Adjustable Belt Speed
Place of Origin Guangdong,China
Brand Name Sunhope
Minimum Order Quantity 1
Price negotiable
Packaging Details wooden case
Delivery Time 60 days
Payment Terms L/C, T/T
Supply Ability 10/set

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Maximum Height Of Workpiece 250mm Temperature Accuracy ±3℃
Nitrogen Consumption About 35～45m 3/h Power Supply AC380V
Size Customized Heating Time 2-3min
Face Height Of Mesh Belt 900mm Nitrogen Purity Above 99.9995%
High Light

Energy Saving Aluminum Brazing Furnace

,

Adjustable Belt Speed Aluminum Brazing Furnace
Leave a Message
Product Description

Energy-Saving Aluminum Brazing Furnace ±3C Temperature Accuracy Adjustable Belt Speed

Product Description:

Aluminum Brazing Furnace is a continuous tunnel type natural gas brazing oven, which is mainly used for brazing aluminum radiators with a maximum height of 250mm. It is equipped with a plug-in heating element that enables a uniform heat distribution. The mesh belt is made of 316L stainless steel braided, providing excellent corrosion resistance. It has a nitrogen consumption rate of 35～45m 3/h, and the nitrogen purity is above 99.9995%. The cooling method is air cooling, ensuring a fast and efficient cooling process.



Technical Parameters:

Parameter Details
Control System PLC Control
Heating Method of brazing section Plug-in Heating Element
Size Customized
Nitrogen Purity Above 99.9995%
Maximum height of workpiece 250mm
Heating up time 0.5-1h
Temperature Accuracy ±3℃
Mesh belt transmission speed 200—1500mm/min (Continuously Adjustable )
Nitrogen consumption About 35～45m 3/h
Material of Mesh belt 316L Stainless Steel Braided


Applications:

Sunhope’s Continuous tunnel type Natural gas brazing oven is the perfect choice for your brazing needs. This oven is made with the highest quality materials, featuring Plug-in Heating Element, 316L Stainless Steel Braided and Above 99.9995% Nitrogen Purity. It is made in Guangdong, China and offers fast heating up time of 0.5-1h. It also has Mesh belt transmission speed of 200—1500mm/min (Continuously Adjustable ) and is perfect for those looking for a reliable and efficient brazing furnace.



Customization:

Aluminum Brazing Furnace

Sunhope Aluminum Brazing Furnace is designed for continuous tunnel type natural gas brazing oven. This furnace is powered by AC380V, three phase 50HZ. It is designed with radiantor tube heating and is capable of controlling temperature accuracy within ±3℃. The face height of the mesh belt is 900mm and is made of 316L stainless steel braided. The nitrogen consumption is about 35～45m 3/h.

Sunhope Aluminum Brazing Furnace is the perfect solution for aluminium brazing needs. With its continuous tunnel type natural gas brazing oven, it offers superior performance and reliable operation.



Support and Services:

Aluminum Brazing Furnace Technical Support and Services

We provide technical support and services for our Aluminum Brazing Furnace. Our team of experts is available to answer any questions you may have. We provide on-site installation, maintenance, and troubleshooting services. Our engineers are experienced in dealing with the complexities of Aluminum Brazing Furnace technology.

We provide ongoing support throughout the life of the product. We offer free technical support via phone, email, and online chat. Our team is available 24 hours a day, 7 days a week. We also offer online tutorials, user manuals, and other resources to ensure that you have the best experience with our Aluminum Brazing Furnace.

If you have any questions or concerns, please don’t hesitate to contact us. We are happy to assist you. Thank you for choosing our Aluminum Brazing Furnace.

Packing and Shipping:

Aluminum Brazing Furnace Packaging and Shipping

The Aluminum Brazing Furnace will be securely packaged in a box lined with foam to ensure its safety during transit. The box will be labeled with the item's name, weight, and any other applicable information.

The box will then be placed in a larger shipping container and shipped via a reliable courier service. The courier will provide tracking information and delivery confirmation.

Upon delivery, the customer should inspect the package for any signs of damage. If any damage is discovered, they should contact the courier immediately.
