350-400 KG Weight 2.5kw Radiator Making Machine Servo Pneumatic Driving
Contact me for free samples and coupons.
Wechat: 0086 18588475571
If you have any concern, we provide 24-hour online help.x
|Power||220V||Header Plate Max Width||120mm|
|Header Plate Max Long||1000mm||Core Height||1100mm|
2.5kw Radiator Making Machine,
Servo Pneumatic Driving Radiator Making Machine
1275mm(L)*1270mm(W)*1880mm (H) Machine Size 350-400 KG Weight Radiator Making machine
Product quick details:
|warranty||12 months||brand name||SUNHOPE|
|Driving mode||Servo pneumatic||Indenter width||20/30/40mm|
|Number of cylinders||8--12||Air pressure requirements||0.8Mpa|
|Core size||1000*900*56mm||Voltage, power||220V/50Hz,2.5kw|
|Maximum size of head plate||120mm||production efficiency||60-80|
|Machine dimensions||1800*1600*1800mm||Number of preset models||200models|
|OEM||welcome||Direction adjustment||3 direction|
- Before signing an official contract with our customer we will help to analyze and provide professional solution based on customer project information and come out with optimum solution.
- Your inquiry related to our products or price will be replied in 24hrs.
- Keep informing our customer production process and help arrange quality checking in the factory if necessary.
- one-year warranty
- Buyer can dispatch technician to our factory for free training before delivery.
- For essential equipment failure, we will arrange our engineer head to local site to help trouble shooting, also provide online technical support for the whole life.
Tanks Pressing Max long 1000mm Head Plate Radiator Making Machine Automatic is the necessary production equipment for aluminum plastic radiator factory.
The device connects the plastic water chamber and the radiator core closely through the air cylinder drive to ensure that the coolant circulates in the radiator, which is the last process to complete the radiator manufacturing.
Features of automatic clinching machine: more than 200 models can be set for positioning press production. It does not need to be pressed by hand, and can press the tab on the four sides of the core at the same time. High production efficiency and high speed. It is suitable for the production mode of single model and quantity production quantity.
Our company has been engaged in the manufacture and development of automobile radiator condenser products for more than 15 years. Most of the products are sold to all countries and regions in the world, and have accumulated rich production experience.Our company is good at manufacturing all the process of the radiator tank production line.In recent years,many companies from other countries in the same industry also bought the CKD from us and purchased the machine equipment from us as well.
At the same time, our company provides customers with all kinds of radiator, condenser required hardware and plastic components. Ensure the supply and quality of finished products.
If you are interested in setting up a radiator factory in your place or buying any products , please contact us and we will provide you with the best service and best price.
1.Is it convenient for workers to operate the semi automatic crimping machine?
The semi automatic crimping machine,the workers only needs to train simply to operate the machine and the operation is convenient and simple.
2.How many types of automatic crimping machine?what ‘s the features of it ?
We can divide them into three types.
A.The first one is single side single crimping head automatic crimping machine.The features are using simply,cheap price.But because the single crimping head tools have the long working cycle,the working efficiency is low.The narrow side tab needs to compress with hands.
B.The second one is single side two crimping heads automatic crimping machine.The features are two crimping heads can work at the same time.The speed and the efficiency is high.The narrow side tab needs to compress with another tools.
C.The third one is single side two crimping heads and the other side also two crimping heads automatic crimping machine.The features are it can finish the crimping of all the whole tanks in the same working stations.The working efficiency is very high.Single side two crimping heads and its narrow side needs to crimp with another clamping tools.The features are when it finishes crimping the long side and needs to crimp the narrow side tab.
3. Automatic crimping machine and semi automatic crimping machine,which one is better?
Automatic crimping machine is suitable for a single model order of 300 sets or more at a time,
semi automatic crimping machine is suitable for this kinds of production plan which is more models but less quantity.
