Intercooler Radiator Core Builder Machine Three Phase 220Volt 50Hz

Place of Origin Guangdong,china
Brand Name sunhope
Model Number SH-ZD800-5Z
Minimum Order Quantity 1
Price negotiable
Packaging Details wooden case with safty packing material
Delivery Time 60days
Payment Terms L/C, T/T
Supply Ability 1set/3 month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Voltage, Power Three-phase 220V 50Hz Driving Mode Servo Motor Driven
Machine Dimensions 2800*2150*2100 Maximum Number Of Flat Tubes Per Row Of Core 42
Maximum Number Of Material Cartridges 50 Tubes Fin Height 8.1mm
Tube Laying Time 0.4s/root
High Light

Intercooler Radiator Core Builder Machine


Three Phase Radiator Core Builder Machine

Leave a Message
Product Description

Intercooler Core Building Radiator Core Builder Machine Three-Phase 220V
Radiator Making Machine introduction

The equipment is composed of motherboard mounting mold, side plate positioning block and core clamping mechanism, flat pipe warehouse, pipe laying mechanism, comb tooth mechanism, transmission mechanism, working platform, fuselage and pneumatic and electrical systems.Flat pipe material warehouse and pipe routing method: automatic pipe routing, need to manually put the flat pipe neatly stacked into the material warehouse, the application of movable vertical storage silo, plus servo motor to automatically move back and forth, automatic discharge and blanking quantity, fixed comb tooth connection, so that each flat pipe automatically put into the fixed comb teeth, the material warehouse can be according to the length of the flat pipe shake handwheel to adjust the corresponding width of the warehouse.


Motherboard installation mold: The mechanism can accurately position the motherboard, the way is hole positioning, the motherboard mold adopts the splicing universal type, according to the length of the main board for general adjustment, the use of splicing to achieve, within the range of equipment can be according to the length of the motherboard to splicing. Achieve the motherboard press-fit into place. When the equipment assembles the main piece, the assembly machine can be walked left and right at the same time, and the assembly can also be carried out step by step.


 Radiator Core Builder Machine quick details


Brand nameSUNHOPE warranty12 months
Surface treatmentvertical bright, transition matte or two-way bright usageautomobile
after-sale serviceyes mouldcan customise
Voltage, powerThree-phase 220V 50Hz ≤8.0KW design stylecan customise
running speedadjustable OEMwelcome
production efficiency60sec. Driving modePneumatics
Number of preset modelsNon. Number of cylinders6--8
Fin height8.1mm Core size700*750*68mm
ProgrammableYes. Workstation1
Device colorIndustrial gray Machine dimensions2800*2150*2100
Changeover time≤20min Machine weight2500kg


Radiator Core Builder Machine Feature

1. The flat pipe material warehouse and pipe routing method are automatic pipe routing

2. The main function of the mechanism is to position the flat tube and limit the gap between the motherboard and the fin

3. Countertop filling

4. Daily maintenance is simple

5. The working position and operating tools can be adjusted manually according to the water chamber structure

6. One workers can operate at the same timepanels
