30secs/Pc 20.5kw Vertical Plastic Automatic Sealer / Dz 500 Vacuum Packaging Machine

Place of Origin Guangdong,china
Brand Name Sunhope
Minimum Order Quantity 1set
Price negotiable
Packaging Details plywood case suitable for sea transportation
Delivery Time 60days
Payment Terms L/C, T/T
Supply Ability 10sets/month
Product Details
Voltage, Power 220V/50Hz,2.5kw Type Vacuum Packing Machine
Packaging Material Plastic Condition New
Automatic Grade Automatic Packaging Type Film
High Light

90secs/Pc Automatic Sealer

,

Dz 500 Vacuum Packaging Machine

,

90secs/Pc vertical vacuum packing machine

Leave a Message
Product Description

30secs/Pc 20.5kw Vertical Plastic Automatic Sealer / Dz 500 Vacuum Packaging Machine

Product descriptions:
    Radiator tank automatic sealer Industrial Vacuum packing machine is also known as thermoplastic molding, this molding process is mainly the use of vacuum suction generated by vacuum pump heating and softening of PVC, PET, PETG, APTT, PP, PE, PS and other thermal plastic sheet through the mold Blister into various shapes of vacuum cover, Blister tray, bubble shell, etc..
      Its main structure is composed of feeding, pulling material, up and down electric heating furnace, lower gate, multi-function adjustable size, lower die plate, upper die, upper gate, knife gate, slicing, putting sheet and with a vacuum device;With pneumatic device as the main power source, the pulling piece, feeding piece adopts electric, reducer, time relay, intermediate relay, travel switch and other electrical appliances composed of automatic control system.
     The requirements of the control system of the blister machine are to ensure easy operation, high precision of mechanical action and temperature control, short production time, and save the power consumption of the machine as far as possible under the same production conditions.

Product parameters:

4 types of machine MANUAL / AUTOMATIC CONTROL MODE OPERATION MODE


FILM ADJUSTED


(Kw)
(800X1100MM)
MAX POWER(Kw)
(800X1100MM)


SPEED

OCCUPIED AREA(LEFT, RIGHT X FRONT,BACK) OPERATING ENVIRONMENT


LABOUR INTENSITY

SEMI-AUTOMATIC VACUUM PLASTIC PACKAGING MACHINE



MANUAL


RELAY

BUTTONS


UNADJUSTABLE

18.5


AVERAGE SPEED IS ABOUT 70-90secs / pc

3000X2400


HIGH-TEMPERATURE


HIGH

SEMI-AUTOMATIC VACUUM PLASTIC PACKAGING MACHINE (RIGHT IN – RIGHT OUT)



AUTOMATIC


RELAY

BUTTONS


UNADJUSTABLE

18-20


45secs / pc

3200X2500


COMFORT


GOOD

AUTOMATIC VACUUM PLASTIC PACKAGING MACHINE (RIGHT IN – LEFT OUT)



AUTOMATIC

PLC HUMAN-MACHINE INTERFACE


ONLY LENGTH CAN BE ADJUSTED

18-21


30-40secs / pc


T TYPE OCCUPIED
4100X2500


COMFORT


GOOD


AUTOMATIC VACUUM PLASTIC PACKAGING LINE




AUTOMATIC


PLC



HUMAN-MACHINE INTERFACE



LENGTH / WIDTH CAN BE ADJUSTED


22-25



30-40secs / pc



L TYPE OCCUPIED

4100X7000



COMFORT



COMFORT


Product applications:
      This type machine can be used for plastic film for all kinds, such as toys, hardware, food, electronics, medicine, with a transparent film coating repacked in a board, form a seal packing.

     This type machine can also produce plastic ceiling panel, cake boxes, lunch boxes, automobile materials and sanitary materials etc, which can be produced with three-dimensional relief pattern like 3D advertisement products.



30secs/Pc 20.5kw Vertical Plastic Automatic Sealer / Dz 500 Vacuum Packaging Machine 0



About us:

      Our company has been engaged in the manufacture and development of automobile radiator condenser products for more than 15 years. Most of the products are sold to all countries and regions in the world, and have accumulated rich production experience.Our company is good at manufacturing all the process of the radiator tank production line.In recent years,many companies from other countries in the same industry also bought the CKD from us and purchased the machine equipment from us as well.
     With the development of heat exchange industry, more and more countries and regions are committed to building local radiator condenser plants. With our understanding of the industry, we have been helping foreign customers to set up radiator factories and provide the production machine in the region in the past five years. We provide customers with pre-sale and after-sale equipment design and service according to the size of our products.In the meantime we will also provide the material to our customers as well. We will send technicians to guide the installation on site to ensure the smooth production of the customer's factory, and provide free consultation service in case of any doubt in the production process.
     At the same time, our company provides customers with all kinds of radiator, condenser required hardware and plastic components. Ensure the supply and quality of finished products.
     If you are interested in setting up a radiator factory in your place or buying any products , please contact us and we will provide you with the best service and best price.




FAQ:

1.Why do you provide the producing equipment of radiator at the same time?

Our company has over 10 years experience in manufacturing the radiator,we are very familiar with all kinds of performance of equipment in the process of manufacturing the radiator.We are able to introduce the customers what’s the best equipment for them according to our experience.



2.Does your company provide after-sales service to the equipment?

Our company has a long term working relationship with the equipment provider,we are very happy to offer the best after-service to our customers.



3.Why do you choose our company to buy the radiator parts?

Our company manufactures and develops hardware moulds by ourselves,we owes over 200 different specifications moulds of head plates ,which covers most of hot sale cars model in the market.



4.Does the after-sales service provided by your company have any advantages?

Because we are also the users of equipment,we have a better understanding in the potential problem which maybe appears in the process of production of equipment.We can provide the fastest and right solution for our customers.
